Now in the industrial production we will often use the inductance of the winding machine, which is the kind of inductance of the winding machine what is the characteristics of it is now with the CNC winding machineManufacturers to come to understand it!

1, the skeleton is refers to the winding bracket. The larger of the fixed inductor or adjustable inductor, most of which will be surrounded on the frame.Then, the inner core or copper core into the heart, skeleton, to increase its inductance. The skeleton is usually made of plastic, bakelite, ceramics, can be made into different shapes according to actual needs. Small inductor generally do not use the skeleton, but directly to the enameled wire wound on the core. Hollow inductor without core, skeleton, and shield, etc., but the first in the mold around the good and then take off the mold and the coil ring between a certain distance.

2, winding is a set of functions with a set of coils, it is the basic component of the inductor. Winding has a single layer and multi layer. A single winding and has close around and around two forms; multilayer winding around a variety of chaos, layered flat around, honeycomb winding method etc..

3, a magnetic core and magnetic bar commonly used such as nickel, zinc, iron, oxygen or Mn Zn ferrite body material, it has "workers" - shaped, cylindrical, and the shape of the cap, "e" shape, cylindrical shape.

4, the core material of silicon steel sheet, slope Mo alloy, its shape is more "E" type.

5, in order to avoid some of the magnetic field generated by the magnetic field in the work of other circuits and components of the normal work, on the increase of the metal screen cover. The inductor with the shield cover can increase the loss of the coil, so that the Q value is reduced.

6, some of the inductor winding, with packaging materials will coil and core sealed. Packaging materials used in plastic or epoxy resin, etc.. Adjustable inductors are commonly used in the adjustable inductor with oscillating coil, TV set with oscillating coil, linear coil, if trap wave coil, audio frequency compensation coil, stop wave coil, etc..
